Model	PRIME H510M-K
CPU Support	Supports Intel® 14 nm CPU
	Supports Intel® Turbo Boost Technology 2.0 and Intel® Turbo Boost Max Technology 3.0**
Chipset	H510
Memory	DDR4 3200(OC)/2933/2800/2666/2400/2133 MHz Non-ECC, Un-buffered Memory*
	Dual Channel Memory Architecture
	Supports Intel® Extreme Memory Profile (XMP)
Graphics	* Graphics specifications may vary between CPU types
Expansion Slots	Intel® 11th & 10th Gen Processors
	1 x PCIe 4.0/3.0 x16 slot
	Intel® H510 Chipset
	1 x PCIe 3.0 x1 slot
Storage	Supports 1 x M.2 slot and 4 x SATA 6Gb/s ports
	Intel® H510 Chipset
	M.2 slot (Key M), type 2242/2260/2280 (supports PCIe 3.0 x4 & SATA modes)
	4 x SATA 6Gb/s ports
Ethernet	1 x Intel® 1Gb Ethernet
USB	Rear USB:Total 6 ports
	2 x USB 3.2 Gen 1 ports (2 x Type-A)
	4 x USB 2.0 ports (4 x Type-A)
Audio	Realtek ALC897/887 7.1 Surround Sound High Definition Audio CODEC*
Back Panel I/O Ports	2 x USB 3.2 Gen 1 ports (2 x Type-A)
	4 x USB 2.0 ports (4 x Type-A)
	1 x D-Sub port
	1 x HDMI™ port
	1 x Intel® I219-V 1Gb Ethernet port
	3 x Audio jacks
	1 x PS/2 Keyboard/Mouse combo port
Internal I/O Connectors	Fan and Cooling related
	1 x 4-pin CPU Fan header
	1 x 4-pin Chassis Fan header
	Power related
	1 x 24-pin Main Power connector
	1 x 8-pin 12V Power connector
	Storage related
	1 x M.2 slot (Key M)
	4 x SATA 6Gb/s ports
	USB
	1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports
	1 x USB 2.0 header supports additional 2 USB 2.0 ports
Miscellaneous	1 x RGB header
	1 x Clear CMOS header
	1 x COM Port header
	1 x Front Panel Audio header (AAFP)
	1 x S/PDIF Out header
	1 x Speaker header
	1 x 10-1 pin System Panel header
Special Features	ASUS 5X PROTECTION III
	- DIGI VRM
	- LANGuard
	- Overvoltage Protection
	- SafeSlot Core
	- Stainless-Steel Back I/O
	ASUS Q-Design
	- Q-DIMM
	- Q-Slot
	ASUS Thermal Solution
	- Aluminum heatsink design
	ASUS Lighting Control
	- RGB header
Software Features	ASUS Exclusive Software
	Armoury Crate
	AI Suite 3
	- Performance And Power Saving Utility
	- TurboV EVO
	- EPU
	- DIGI VRM
	- Fan Xpert
	- EZ update
	ASUS CPU-Z
	AI Charger
	DAEMON Tools
	Norton Anti-virus software (Free Trial version)
	WinRAR
	UEFI BIOS
	ASUS EZ DIY
	- ASUS CrashFree BIOS 3
	- ASUS EZ Flash 3
	- ASUS UEFI BIOS EZ Mode
BIOS	128 Mb Flash ROM, UEFI AMI BIOS
Manageability	WOL by PME, PXE
Accessories	Cables
	2 x SATA 6Gb/s cables
	Miscellaneous
	1 x I/O Shield
	1 x M.2 ANCHOR
	Installation Media
	1 x Support DVD
	Documentation
	1 x User manual
Form Factor	microATX
	22.6cm x 20.3cm
